VIENTO BIKE

Grvel Bike

$1,980.00
Choose size
Choose build kit

The word VIENTO is known in Spanish as WIND. Our version of the VIENTO is one that describes the feeling of floating in the wind.

KEY FEATURES

Frame Material Carbon
Fork 396mm A to C Disc Road for 700c
Drivetrain 2X
Bottle Mounts 3X
Dropouts Fixed 142 X 12mm
Rack Mounts Yes
Bottom Bracket BSA 73mm
Seatpost 27.2mm
Headset FSA Orbit C-40-ACB

Viento Gravel Bike

The word VIENTO is known in Spanish asWIND. Our version of the VIENTO is one that describes the feeling of floating in the wind; a powerful force that constantly moves forward and crushing monster mountain climbs like the wind . ThisViento Gravel Bike and frame was designed with all-day ride handling comfort without any loss of performance.  The components on the Viento have been carefully selected to give the best balance for a gravel road experience that is smooth and flawless.  Like allVooDoo bicycles,  this also has the perfect balance of geometry, materials, and component setup to help the rider go further, for longer and faster than over smooth or rough terrain.  Thru-axles front and rear help to enable solid and stable hub to frame/fork interface with quick wheel changes. You will be enamored that a carbon bike like this adapts to the best of all worlds. Enjoy the Viento and rest with the thought in your mind of “Go with the wind."

GEOMETRY
  • VIENTO 700c Disc︱CARBON GRAVEL Disc 700c
  • FORK︱Carbon Disc 700c Tapered Flat Mount
  • SHIFTERS︱SB Force eTap AXS Electronic Hydraulic Disc, front caliper, left control, front shifter, 0mm flat mount, 900mm hose; SB Force Hydraulic Disc, rear caliper, right control, rear shifter, 0mm flat mount, 1750mm hose, In-Line Connectamajig
  • CRANK︱SRAM FORCE 1 D1 DUB 172.5mm 38t Crankset
  • REAR DERAILLEUR︱SRAM FORCE eTap AXS Rear Derailleur 33T Maximum Rear Cog
  • CASSETTE/COG︱SRAM XG-1270, 10-33 : 12-speed
  • CHAIN︱SRAM Force AXS 12-speed, 116 links
  • BOTTOM BRACKET︱Truvativ/SRAM DUB : BB DUB BB386 86.5 ROAD
  • WHEELS (F/R)︱Easton EC90AX Road/Gravel Disc 100 X 12 & 142 X 12
  • BRAKE CALIPERS/LEVERS︱SRAM FORCE - Included above
  • BRAKE ROTORS︱SRAM Centerline CLX R Centerlock 160mm front / rear Rounded Rotor
  • BRAKE ROTOR PART︱Tektro Centerloc Adaptor
  • TIRES︱WTB Raddler 700 X 44 Tan Sidewall, Distance+ Compound, Supple Tubeless Casing, TCS Aramid Bead
  • TUBES︱700c 35 to 45c with 48mm Presta valve
  • SKEWERS︱DT Swiss Thru-axle F/R
  • HEADSET︱FSA Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ), alloy crown race (H2166B) Orbit C-40-ACB
  • STEM︱Easton EA70 31.8mm Clamp 0 deg 80, 90, 100, 110
  • HANDLEBARS︱Easton EC70AX 31.8mm Clamp 40, 42, 44 cm
  • BARTAPE/GRIPS︱Easton Micro-Tex Black Bar-Tape
  • SPACERS︱10mm spacers
  • SADDLE︱WTB SL8 TEAM with Ti Rails
  • SEAT POST︱Easton EC90 27.2mm X 350mm X 0mm SB
  • SEAT POST CLAMP︱Ten on Ten Seatpost Collar 32mm (Black with Logo)
  • PEDALS︱Wellgo C172DU Road/Hybrid pedal
  • CABLES AND HOUSING︱SRAM Cable Housing
  • Carbon Gravel Road︱Carbon Fiber Gravel Road Bike
  • FORK︱Carbon Disc 700c Tapered; 396mm A to C; 100mm X 12mm Thru-Axle
  • SHIFTERS︱DB HRD FRC CX1 ICJ FRONT/LEFT DIR 900mm hose; SB Force Hydraulic Disc, rear caliper, right control, rear shifter,Flat Mount Rear, 1750mm hose, In-Line Connectamajig
  • CRANK︱FC FORCE1 24MM 1725 XSYNC 38
  • REAR DERAILLEUR︱RD RD FORCE1 LONG CAGE
  • CASSETTE/COG︱SRAM PG-1170, 11-32 11-speed
  • CHAIN︱SRAM PC1170 11-speed, 116 links
  • BOTTOM BRACKET︱Truvativ/SRAM DUB Threaded BSA 68mm Road
  • WHEELS (F/R)︱Easton EA90AX Road/Gravel Disc
  • BRAKE CALIPERS/LEVERS︱SRAM FORCE 22 - Included above
  • BRAKE ROTORS︱SRAM Centerline CLX R Centerlock 160mm front / rear Rounded Rotor
  • BRAKE ROTOR PART︱Tektro Centerloc Adaptor
  • TIRES︱WTB Raddler 700 X 44 Tan Sidewall, Distance+ Compound, Supple Tubeless Casing, TCS Aramid Bead
  • TUBES︱700c 35 to 45c with 48mm Presta valve
  • SKEWERS︱DT Swiss Thru-axle F/R
  • HEADSET︱FSA Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ), alloy crown race (H2166B) Orbit C-40-ACB
  • STEM︱Easton EA70 31.8mm Clamp 0 deg 80, 90, 100, 110
  • HANDLEBARS︱Easton EA70 AX 31.8mm Clamp 42, 44, 46 cm
  • BARTAPE/GRIPS︱Easton Micro-Tex Black Bar-Tape
  • SPACERS︱10mm spacers
  • SADDLE︱WTB SL8 TEAM with Ti Rails
  • SEAT POST︱EA70 SP 0MM 400 27.2 OE
  • SEAT POST CLAMP︱Ten on Ten Seatpost Collar 32mm (Black with Logo)
  • PEDALS︱Wellgo C172DU Road/Hybrid pedal
  • CABLES AND HOUSING︱SRAM Cable Housing
  • VIENTO 700c Disc︱Carbon Disc Gravel Road 700c
  • FORK︱Carbon Disc 700c Tapered; 396mm A to C; 100mm X 12mm Thru-Axle
  • SHIFTERS︱DB Rival Hydraulic Disc, front caliper, left control, 20mm Flat Mount, 900mm hose; Shifter/Brake Rival Hydraulic, in-line Connect-a-majig, rear caliper, right control, rear shifter, Flat Mount, 1750mm hose, no frame mounting bolts
  • CRANK︱SRAM Rival 1 GXP 172.5mm 38t Crankset
  • REAR DERAILLEUR︱RD RIVAL1 LONG CAGE
  • CASSETTE/COG︱SRAM PG-1130, 11-32 11-speed
  • CHAIN︱SRAM PC1130 11-speed, 114 links
  • BOTTOM BRACKET︱Truvativ/SRAM GXP XR BB
  • WHEELS (F/R)︱Easton EA70AX Road/Gravel Disc
  • BRAKE CALIPERS/LEVERS︱SRAM RIVAL 22 - Included above
  • BRAKE ROTORS︱SRAM Centerline CLX R Centerlock 160mm front / rear Rounded Rotor
  • BRAKE ROTOR PART︱Tektro Centerloc Adaptor
  • TIRES︱WTB Raddler 700 X 44 Tan Sidewall, Distance+ Compound, Supple Tubeless Casing, TCS Aramid Bead
  • TUBES︱700c 35 to 45c with 48mm Presta valve
  • SKEWERS︱DT Swiss Thru-axle F/R
  • HEADSET︱FSA Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ), alloy crown race (H2166B) Orbit C-40-ACB
  • STEM︱Easton EA50 31.8mm Clamp 8 deg (80, 90, 100, 110)
  • HANDLEBARS︱Easton EA50AX 31.8mm Clamp 40, 42cm, 44cm
  • BARTAPE/GRIPS︱Easton Micro-Tex Black Bar-Tape
  • SPACERS︱10mm spacers
  • SADDLE︱WTB SL8 Pro with Cromo Rails
  • SEAT POST︱Easton EA50 27.2mm X 350mm X 12mm SB
  • SEAT POST CLAMP︱Ten on Ten Seatpost Collar 32mm (Black with Logo)
  • PEDALS︱Wellgo LU-895DU Mountain Bike Pedals
  • CABLES AND HOUSING︱SRAM Cable Housing
  • 42CM ︱ 4'8"-5'2" FT ︱ 142-157 CM
  • 45CM ︱ 5'2"-5'6" FT ︱ 157-167 CM
  • 48CM ︱ 5'6"-5'11" FT ︱ 167-180 CM
  • 51CM ︱ 5'11"-6'3" FT ︱ 180-190 CM
  • 54.5CM ︱ 6'3"-6'6" FT ︱ 190-198 CM
  • 58CM ︱ 6'6"-6'9" FT ︱ 198-205 CM
